Air ratchet hand tool with thermoplastic jacket

Published
Permanent URL
Classification
Tools & Tooling › Fastening Tools
Assignee
SNAP ON TOOLS CO
Original source
US-5992540-A, the United States Patent and Trademark Office, 30 November 1999
Document SHA-256
b877b4678c2e44578e869bc866042bc9e28489f28a0d23deb75dec672d268c74

An air ratchet hand tool has an elongated, generally cylindrical handle portion with an axial air inlet passage therethrough, and having an outer surface with two longitudinally extending channels formed therein, each communicating with the air motor. A thermoplastic grip jacket covers the handle portion and cooperates with the channels to form therebetween two exhaust air passages which exit at the distal end of the handle. Longitudinal ribs on the jacket project radially inwardly into engagement with longitudinal recesses in the handle portion to inhibit relative rotational movement, while a lug on the handle portion extends through an opening in the jacket to inhibit relative axial movement. A flexible and resilient trigger cover covers the valve trigger and the jacket opening through which it projects.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3
Sheet 4
Sheet 4
Sheet 5
Sheet 5

Abstract

An air ratchet hand tool has an elongated, generally cylindrical handle portion with an axial air inlet passage therethrough, and having an outer surface with two longitudinally extending channels formed therein, each communicating with the air motor. A thermoplastic grip jacket covers the handle portion and cooperates with the channels to form therebetween two exhaust air passages which exit at the distal end of the handle. Longitudinal ribs on the jacket project radially inwardly into engagement with longitudinal recesses in the handle portion to inhibit relative rotational movement, while a lug on the handle portion extends through an opening in the jacket to inhibit relative axial movement. A flexible and resilient trigger cover covers the valve trigger and the jacket opening through which it projects.
