Modular storage and display device

Published
Permanent URL
Classification
Tools & Tooling › Clamping Tools
Original source
US-5931315-A, the United States Patent and Trademark Office, 3 August 1999
Document SHA-256
61ded2a9b000ebe5f688cca272047068a8a49d7613e2c423836910e49f67f768

A modular storage and display device for essentially flat containers. The display device has a vertically retained column and a plurality of connecting members mounted on the column. The connecting members have a pair of resiliently displaceable gripping arms integrally formed at one portion of the connecting members. The arms are adapted to snap fit around the column so the connecting member is rotatable around and slidable along the longitudinal axis of the column. A system for gripping an edge portion of the container is disposed on another portion of the connecting member.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3
Sheet 4
Sheet 4
Sheet 5
Sheet 5
Sheet 6
Sheet 6
Sheet 7
Sheet 7
Sheet 8
Sheet 8
Sheet 9
Sheet 9
Sheet 10
Sheet 10

Abstract

A modular storage and display device for essentially flat containers. The display device has a vertically retained column and a plurality of connecting members mounted on the column. The connecting members have a pair of resiliently displaceable gripping arms integrally formed at one portion of the connecting members. The arms are adapted to snap fit around the column so the connecting member is rotatable around and slidable along the longitudinal axis of the column. A system for gripping an edge portion of the container is disposed on another portion of the connecting member.

1. Drawings

[0001]Sheet 1.

[0002]Sheet 2.

[0003]Sheet 3.

[0004]Sheet 4.

[0005]Sheet 5.

[0006]Sheet 6.

[0007]Sheet 7.

[0008]Sheet 8.

[0009]Sheet 9.

[0010]Sheet 10.
