Vibration damping structure for use with a machine tool

Published
Permanent URL
Classification
Manufacturing & Assembly Equipment › Machining Systems
Original source
US-5765818-A, the United States Patent and Trademark Office, 16 June 1998
Document SHA-256
f69a495da599deb98d6de2a2d46b5e8b1c63c0d323ed6712e08b193c60a70678

A vibration damping structure for a machine tool is provided. The structure includes first and second plate members disposed in an opposing spaced apart relationship with one another. A cast structure formed of a polymer concrete extends between the first and second plate members. A first structure is attached to the first plate member and extends inwardly of the cast structure. The first structure has a compression surface extending in a spaced apart relationship from the surface of the first plate member. A second structure is attached to the second plate member and extends inwardly of the cast structure. The second structure has a compression surface extending in a spaced apart relationship from the surface of the second plate member and in an opposed spaced apart interlocking relationship with the compression surface of the first structure so that tensile forces applied to the first and second plate members will correspondingly produce compression forces between the opposing compression surfaces and the damping material therebetween.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3
Sheet 4
Sheet 4
Sheet 5
Sheet 5
Sheet 6
Sheet 6
Sheet 7
Sheet 7
Sheet 8
Sheet 8
Sheet 9
Sheet 9
Sheet 10
Sheet 10

Abstract

A vibration damping structure for a machine tool is provided. The structure includes first and second plate members disposed in an opposing spaced apart relationship with one another. A cast structure formed of a polymer concrete extends between the first and second plate members. A first structure is attached to the first plate member and extends inwardly of the cast structure. The first structure has a compression surface extending in a spaced apart relationship from the surface of the first plate member. A second structure is attached to the second plate member and extends inwardly of the cast structure. The second structure has a compression surface extending in a spaced apart relationship from the surface of the second plate member and in an opposed spaced apart interlocking relationship with the compression surface of the first structure so that tensile forces applied to the first and second plate members will correspondingly produce compression forces between the opposing compression surfaces and the damping material therebetween.
