Caster device

Published
Permanent URL
Classification
Tools & Tooling › Clamping Tools
Original source
US-5479677-A, the United States Patent and Trademark Office, 2 January 1996
Document SHA-256
9c436f2d3a91f61fc27d1e6ee90d392140290ae0a4e0bbc401ac3f026725ff14

A caster device for supporting a push cart includes a cap member having a flat top fixed to the push cart and a circular side wall. The circular side wall of the cap member has an inwardly curled lower edge. An inverted and truncated conical ring member has a curved side wall and a flange. A bowl-shaped rotary member is disposed below the ring member such that a horizontal flange thereof abuts the flange of the ring member. The side wall of the rotary member and the curved side wall of the ring member cooperatively define a first annular ball-receiving space. The horizontal flange and the side wall of the rotary member, and the inwardly curled lower edge of the cap member cooperatively define a second annular ball-receiving space. A plurality of steel balls are rotatably confined within the first annular ball-receiving space and the second annular ball-receiving space to permit rotation of the rotary member with respect to the cap member.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3
Sheet 4
Sheet 4
Sheet 5
Sheet 5
Sheet 6
Sheet 6
Sheet 7
Sheet 7
Sheet 8
Sheet 8

Abstract

A caster device for supporting a push cart includes a cap member having a flat top fixed to the push cart and a circular side wall. The circular side wall of the cap member has an inwardly curled lower edge. An inverted and truncated conical ring member has a curved side wall and a flange. A bowl-shaped rotary member is disposed below the ring member such that a horizontal flange thereof abuts the flange of the ring member. The side wall of the rotary member and the curved side wall of the ring member cooperatively define a first annular ball-receiving space. The horizontal flange and the side wall of the rotary member, and the inwardly curled lower edge of the cap member cooperatively define a second annular ball-receiving space. A plurality of steel balls are rotatably confined within the first annular ball-receiving space and the second annular ball-receiving space to permit rotation of the rotary member with respect to the cap member.
