Quick release disconnect coupling device for drive shaft segments

Published
Permanent URL
Classification
Tools & Tooling › Clamping Tools
Original source
US-5360376-A, the United States Patent and Trademark Office, 1 November 1994
Document SHA-256
a22c555d344bafdbef8221201da93b53a71a9b0f44b02ea70eef7ffa71847d32

A coupling device for transmitting torque between two rotating drive shaft segments. The coupling device includes a locking mechanism for preventing axial excursions of the drive shaft segments relative to one another when the drive shaft segments are coupled and transmitting torque. The coupling device, furthermore, provides a means for quick disconnect of the drive shaft segments when the transmission of torque is no longer desired and decoupling is preferred. The coupling device, additionally, includes a guide pin and sleeve arrangement for piloting the drive shaft segments during coupling. A drive system is also provided which includes a flexible coupling for accommodating axial and angular misalignment of the drive shaft segments relative to one another.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3
Sheet 4
Sheet 4
Sheet 5
Sheet 5
Sheet 6
Sheet 6

Abstract

A coupling device for transmitting torque between two rotating drive shaft segments. The coupling device includes a locking mechanism for preventing axial excursions of the drive shaft segments relative to one another when the drive shaft segments are coupled and transmitting torque. The coupling device, furthermore, provides a means for quick disconnect of the drive shaft segments when the transmission of torque is no longer desired and decoupling is preferred. The coupling device, additionally, includes a guide pin and sleeve arrangement for piloting the drive shaft segments during coupling. A drive system is also provided which includes a flexible coupling for accommodating axial and angular misalignment of the drive shaft segments relative to one another.
