Device for mounting and transporting substrates in vacuum apparatus

Published
Permanent URL
Classification
Material Handling › Conveying Systems
Inventors
GEISLER MICHAEL, JUNG MICHAEL
Assignee
LEYBOLD AG
Original source
US-5259603-A, the United States Patent and Trademark Office, 9 November 1993
Document SHA-256
6c4c78bb385885094c4d60cafa947635c9e179bc501694696476fba6f1f57190

Device for mounting thin, preferably flat substrates (11, 11', . . . ) and for the transport of these substrates (11, 11'. . . ) in treatment apparatus, for example vacuum coating and etching apparatus, the device being formed by a frame (1), preferably in a rectangular shape, which is of such size that in the area surrounded by the frame (1) a support, e.g., a support formed of spoke-like round rods (6, 6', . . . ). can be inserted, and on this support fastening means for mounting the substrates (11, 11', . . . ) are provided, which hold the substrates (11, 11', . . . ) such that their substantially planar lateral surfaces run approximately parallel to the plane of the frame.

Sheet 1
Sheet 1
Sheet 2
Sheet 2
Sheet 3
Sheet 3

Abstract

Device for mounting thin, preferably flat substrates (11, 11', . . . ) and for the transport of these substrates (11, 11'. . . ) in treatment apparatus, for example vacuum coating and etching apparatus, the device being formed by a frame (1), preferably in a rectangular shape, which is of such size that in the area surrounded by the frame (1) a support, e.g., a support formed of spoke-like round rods (6, 6', . . . ). can be inserted, and on this support fastening means for mounting the substrates (11, 11', . . . ) are provided, which hold the substrates (11, 11', . . . ) such that their substantially planar lateral surfaces run approximately parallel to the plane of the frame.
